BLUESEAL ULTRA — Kinetics Line

Save or print this datasheet

Note: Data shown are typical laboratory results provided as non-binding guidance. Max temperature and max pressure ratings are not for simultaneous use; allowable pressure decreases as temperature increases.

BLUESEAL ULTRA is a general-purpose gasket material based on aramid fibres, inorganic fillers and NBR binder. The formulation gives the material excellent chemical stability and resistance to creep, combining very good thermomechanical properties and chemical resistance.

Well-suited for gas and potable water supplies. Key approvals: BAM (oxygen service), DVGW, WRAS, SVGW, ABS, DNV, EC 1935/2004.

Typical Applications

Gas supply

Potable water supply

Chemical industry

Petrochemical industry

Food industry

Heating & cooling systems

Compressors & pumps

Shipbuilding

Technical Properties

Property	Value	Technical Meaning
Material Density DIN 28090-2	1.7g/cm³	High density aramid fibre matrix ensures robust sealing performance under load.¹
Compressibility ASTM F36J	11%	Good conformability to flange surface irregularities under bolt load.²
Elastic Recovery ASTM F36J	60%	High recovery ensures seal integrity under thermal cycling and dynamic loading.²
Tensile Strength ASTM F152	12MPa	High mechanical strength ensures gasket integrity under demanding installation and service conditions.³
Residual Stress DIN 52913 · 175°C / 16h	27MPa	Retains sealing force under heat and load. 23 MPa at 300°C — reducing re-torque needs.⁴
Specific Leak Rate DIN 3535-6	0.02mg/s·m @ 2.0 mm	Very low leak rate — excellent for emission-controlled and gas service applications.⁵
Thickness Increase ASTM F146 · Oil IRM 903 / Fuel B	Oil 2% Fuel 5%	Oil IRM 903 (150°C, 5h) / Fuel B (23°C, 5h) — low swell confirms dimensional stability.⁶
Max. Service Temperature Continuous: 250°C · Steam: 200°C	350°C	Peak 350°C; continuous 250°C; steam 200°C.
Max. Operating Pressure	100bar	High pressure capability for demanding industrial applications.

Certifications & Approvals

Gas & Water

Oxygen serviceBAM

Gas (Germany)DVGW DIN 30653 HTB

Gas (Germany)DVGW DIN 3535-6

Gas (Switzerland)SVGW DIN 3535-6

Water (UK)WRAS

Marine & Food

MarineABS

MarineDNV

Marine (Australia)AGA AS 4623

Food contactEC 1935/2004

Standard Supply Data

Sheet Sizes

1500 × 1500 mm

Also 4500 × 1500 mm

Thickness

0.5 / 1 / 1.5 / 2 / 3 mm

± 10% >1mm · ± 0.1mm ≤1mm

Colour

Blue

Brand standard

Surface Finish

Antistick — both sides

Minimizes flange adhesion · 4AS standard

Test Standards & Notes

DIN 28090-2: Material density

DIN 52913: Residual stress 27 MPa (175°C / 16h) · 23 MPa (300°C)

ASTM F36J: Compressibility & Elastic Recovery

DIN 3535-6: Specific leak rate @ 2.0 mm thickness

ASTM F152: Tensile strength

ASTM F146: Thickness increase — Oil IRM 903 (150°C, 5h) / Fuel B (23°C, 5h)
