Note: Data shown are typical laboratory results provided as non-binding guidance. Max temperature and max pressure ratings are not for simultaneous use.
GREENSEAL PRO 180 is a non-asbestos jointing sheet based on cellulose and synthetic fibres with inorganic fillers, bonded in an NBR binder matrix.
Suitable for thermo-hydraulic applications at low bolt loads. Approved for use with potable water, foodstuffs, oils, alcohols and glycols. Antistick surface finish on one side minimizes flange adhesion and simplifies gasket replacement.
Typical Applications
Water supply & distribution systems
General-purpose industrial piping
Food & beverage processing
Thermo-hydraulic flanges at low bolt loads
Shipbuilding & marine auxiliary systems
Heating & cooling circuits
Technical Properties
Property
Value
Technical Meaning
Max. Service Temperature
Continuous: 140°C · Steam: 120°C
180°C
Short-term peak. Continuous limit 140°C; steam max 120°C.2
Max. Operating Pressure
Standard flange assemblies
40bar
Rated pressure for standard flange assemblies.3
Compressibility
ASTM F36
9%
Conforms to flange surface irregularities under bolt load.1
Elastic Recovery
ASTM F36
60%
Maintains seal integrity during pressure fluctuations.1
Tensile Strength
ASTM F152 · across grain
8MPa
Resistance to tearing across fibre grain.4
Residual Stress
DIN 52913 · 50MPa / 175°C / 16h
20MPa
Remaining clamping force after prolonged heat exposure.5
Specific Leak Rate
DIN 3535-6 · nitrogen
0.04mg/s·m
@ 2.0 mm
Low nitrogen leakage for standard industrial service.7
Thickness Increase — Oil
ASTM F146 · IRM 903 / 150°C / 5h
10%
Low swell confirms stability in oil-wetted flanges.7
Thickness Increase — Fuel
ASTM F146 · Fuel B / 23°C / 5h
10%
Confirms suitability for fuel lines and petroleum service.7
