Note: Data shown are typical laboratory results provided as non-binding guidance. Max temperature and max pressure ratings are not for simultaneous use; allowable pressure decreases as temperature increases.
RUBBERSEAL PRO 110 is a high-quality EPDM elastomer extrusion compound (80 Shore A) based on Ethylene Propylene Diene M-class rubber. Engineered for outstanding weather resistance and wide-temperature sealing performance.
Excellent resistance to ozone, UV radiation, oxidation and weather agents makes it ideal for outdoor and long-term applications. FDA compliant for food-contact use. High elongation at break ensures seal integrity under mechanical stress and movement.
Typical Applications
Outdoor sealing & weatherstripping
Water & steam systems (to 110°C)
Food & beverage processing (FDA)
HVAC & refrigeration systems
Construction sealing profiles
Automotive & OEM gasket extrusions
Technical Properties
Property
Value
Technical Meaning
Working Temperature Range
Continuous · Hot air peak 130°C
-40/+110°C
Full operational range from deep cold to +110°C continuous; hot air resistance peaks at 130°C short-term.4
Hardness
Shore A · ISO 868
80ShA
High hardness suitable for stable sealing shapes and consistent compression under bolt load.
Density
ISO 2781
1.409g/cm³
Specific gravity value confirming high-grade EPDM compound consistency and material uniformity.2
Tensile Strength
ISO 37 Type 1
5.5MPa
Mechanical resistance under tensile load. Ensures the compound withstands installation stress and service forces.1
Elongation at Break
ISO 37 Type 1
307%
High flexibility — allows significant stretching without failure. Critical for sealing profiles under dynamic movement.1
Tearing Resistance
ISO 37 Type 1
3N/mm²
Resistance to tearing propagation under stress. Ensures long-term integrity of sealing profiles in service.1
Compression Set
ISO 815 B
47%
Permanent deformation measured after sustained compression. Lower is better for long-term sealing force retention.3
Weather Resistance
Ozone · UV · Oxidation
Excel lent
Full resistance to ozone, UV radiation, oxidation and weather agents. Suitable for permanent outdoor exposure.6
Chemical & Media Resistance
✓ Excellent
Weather agents / Ozone
Water / Sea water
~ Good
Hot air (to 130°C)
Steam
Ketones
Bases / Alkalis
Low temp. stiffness
✗ Not Recommended
Aliphatic hydrocarbons
Paraffin mineral oils
Chlorinated solvents
Flame
Certifications & Approvals
Gas & Water
Germany (Gas)DVGW DIN 3535-6
Germany (Water)TZW W270
United KingdomWRAS
Food & Standards
Food contactEU 1935/04
Standard Supply Data
Material
EPDM Extrusion
Custom profiles on request
Hardness
80 Shore A
± 5 ShA tolerance
Colour
Black
Brand standard
Temperature Range
-40 / +110°C
Hot air peak 130°C
Test Standards & Notes
1
ISO 37 Type 1: Tensile strength, elongation & tearing resistance
4
Temperature: -40°C to +110°C continuous · Hot air 130°C peak
